Board To Board Connector

11 parts

11 verified Board To Board Connector parts from the JLC/LCSC catalog. Every entry ships with schematic symbol and PCB footprint, plus datasheet mirror and 3D model where available — ready to drop into a design headed for JLC assembly.

	Part	LCSC	Description	Package	JLC class
	HC-PBB40C-20DS-0.4V-3.0-02 HCTL(华灿天禄)	C19089284	20P 0.4mm vertical SMT board-to-board connector, Slot Type Butting, 2 rows, 300mA, system fit height 3mm, gold plating	SMD,P=0.4mm	Extended Part
	HC-PBB40C-20DS-0.4V-4.0-02 HCTL(华灿天禄)	C19089314	20P 0.4mm vertical SMT board-to-board connector, Slot Type Butting, 2 rows, 300mA, system fit height 4mm, gold plating	SMD,P=0.4mm	Extended Part
	DF40C-100DS-0.4V(51) HRS(Hirose)	C597931	100P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting. The Raspberry Pi Compute Module 4/5 mates to a pair of these.	SMD	Extended Part
	BM54B3.0-30DS-0.4V(51) HRS(广濑)	C31736941	30P 0.4mm vertical SMT board-to-board connector, 50V, 2 rows, 300mA, gold plating, -55°C~+125°C	SMD,P=0.4mm	Extended Part
	DF40B-30DS-0.4V(51) HRS(广濑)	C17701736	30P 0.4mm vertical SMT board-to-board connector, 2 rows, Slot Type Butting, phosphor bronze contacts, gold plating	SMD,P=0.4mm	Extended Part
	DF40C(2.0)-20DS-0.4V(51) HRS(广濑)	C597932	20P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C	SMD,P=0.4mm	Extended Part
	DF40C(2.0)-30DS-0.4V(51) HRS(广濑)	C597933	30P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C	SMD,P=0.4mm	Extended Part
	DF40C-120DS-0.4V(51) HRS(广濑)	C3647197	120P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C	SMD,P=0.4mm	Extended Part
	DF40C-20DS-0.4V(51) HRS(广濑)	C424638	20P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C	SMD,P=0.4mm	Extended Part
	DF40C-30DS-0.4V(51) HRS(广濑)	C424642	30P 0.4mm vertical SMT board-to-board connector, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C	SMD,P=0.4mm	Extended Part
	DF40C-30DS-0.4V(58) HRS(广濑)	C7265089	30P 0.4mm vertical SMT board-to-board connector, 30V, 2 rows, 300mA, Slot Type Butting, gold plating, -35°C~+85°C	SMD,P=0.4mm	Extended Part
